UNIVIEW MW3586-U-X 86'' Smart Interactive Display

Panel Size

86"

Resolution

3840 x 2160

Brightness (cd/m²)

350

Contrast Ratio

1200:1

Response Time (ms)

8

Color Support

1.07B

Viewing Angle (H/V)

178°/178°

Refresh rate（Hz）

60

Color gamut

72%

Lifespan

50000H

Surface Hardness

9H (7 on the Mohs scale)

Haze Value

25%

Display Size（mm）

1895.04 x 1065.96

Pixel Pitch (H x V) (mm)

0.49 x 0.49

RAM

DDR4, 4GB

ROM

eMMC, 32GB

CPU

Amlogic T982 quad‑core A55

CPU Frequency

1.9GHz

Operation System

Android 13.0

Touch Control

Supports 32‑point touch, 20‑point write

Recognizable Object

5 points, 3mm

Touch Precision (mm)

1

Glass

4mm tempered glass, 7H (Mohs), anti‑glare

Touch Response Time (ms)

≤5

Touch technology

Infrared touch

Video Input

2 x HDMI IN (4K@60)

2 x AV analog video input

Video Output

1 x AV analog video output

Audio Output

1 x earphone, 3.5mm interface

Other Interfaces

1 x SPDIF, 1 x RS232, 1 x USB 3.0, 4 x USB 2.0, 1 x USB Type‑C, 2 x TOUCH OUT

Network

1 x RJ45, supports 10M/100M Base‑T self‑adaptive

Operating Voltage

AC 100V to 240 V, 50/60 Hz

Overall Power Consumption (W)

236

Product Dimensions (W x H x D) (mm)

1969.8 x 1151 x 115.9 (Without camera)

Package Dimensions (W x H x D) (mm)

2085 x 1276 x 220

Operating Temperature

0°C to 50°C

Operating Humidity

10% to 90% RH (noncondensing)

Accessories Included

1 x power cable, 2 x touch pen, 1 x quick guide, 1 x wall mount bracket, 1 x infrared remote control, 3 x rod antenna

Speaker

2.0 sound channel

Left channel: 1 x 15W, 8Ω

Right channel: 1 x 15W, 8Ω

Wi-Fi Configuration

Built‑in dual‑frequency Wi‑Fi 5 module

Supports AP and station modes

Wi-Fi Performance

Up to 20m transmission distance in open space

Bluetooth Version

5.0

Multi-Language

23 (Simplified Chinese, Traditional Chinese, Japanese, German, English, Spanish, French, Italian, Portuguese, Russian, Korean, Vietnamese, Ukrainian, Hungarian, Polish, Thai, Arabic, Kazakh, Bulgarian, Galician, Catalan, Uzbek, Indonesian)
