IP CAM UNV IPC542SE-HDK-I0

Sensor

1/2.8" CMOS

Min. Illumination

Colour:0.0005lux (F1.2, AGC ON)

B/W: 0.0001Lux(F1.2, AGC ON)

Day/Night

IR-cut filter with auto switch (ICR)

Shutter

Auto/Manual, 1 to 1/100000 s

WDR

120 dB

S/N

>52 dB

ABF

N/A

Lens Mount

C/CS

Iris

F1.2

Video Compression

Ultra 265, H.265, H.264, MJPEG

Frame Rate-Main Stream

2MP (1920*1080), Max 60fps

Video Bit Rate

128 Kbps to 16 Mbps

U-code

Support

Frame Rate-Sub Stream

720P (1280*720), Max 60fps

ROI

Support

Video Stream

Triple Streams

OSD

Up to 8 OSDs

Privacy Mask

Up to 4 areas

Frame Rate-Third Stream

D1 (720*576), Max 60fps

White Balance

Auto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2

Digital Noise Reduction

2D/3D DNR

Flip

Normal, Flip Vertical, Flip Horizontal, 180°, 90° Clockwise, 90° Anti-clockwise

HLC

Support

BLC

Support

Defog

Digital Defog

Heatwave Reduction

N/A

Smart Intrusion Prevention

Cross line detection, intrusion detection, enter area detection, leave area detection (support false alarm filtering and the classification of human, non-motor vehicle and vehicle)

People Counting

Support People Flow Counting and Crowd Density Monitoring

Exception Detection

Object Removed, Object Left Behind, Scene Change

Basic Detection

Motion Detection, Tampering Alarm, Audio Detection, Object Removed, Object Left Behind, Scene Change

General Function

Watermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication, Alarm Input, Alarm Output

Audio Compression

G.711U, G.711A

Audio Bitrate

128 Kbps

Two-way Audio

Support

Suppression

Support

Sampling Rate

16KHZ

Edge Storage

Micro SD, up to 512 GB

Network Storage

ANR, NAS (NFS)

Protocols

SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS

Compatible Integration

ONVIF (Profile S, Profile G, Profile T),

API, SDK

User/Host

Up to 32 users. 3 user levels: administrator, common user and operator

Security

TLS 1.3, Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF

Client

EZStation, UNV-Link, UNV-Link Pro

Web Browser

Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+

Audio I/O

1 Input: impedance 1 kΩ, amplitude 2.5 V [p-p], 1 Output: impedance 600 Ω, amplitude 2.5 V [p-p]

Alarm I/O

2/1

Serial Port

1 channel RS485 interface

Network

1 × RJ45 10 M/100 M Base-TX Ethernet

Video Output

1 BNC (For debugging)

EMC

CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020)

FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)

Safety

CE LVD (EN 62368-1:2014+A11:2017)

UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)

Environment

CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)

Power

DC12V(±25%), AC24V(±25%), PoE(IEEE 802.3af)

Power Consumption

Max 7W

Power Interface

Two-core terminal block

Dimensions

152 x 71 x 65 mm (6.0" x 2.8" x 2.6") (L x W x H) (excluding the lens)

Weight

0.38kg (0.84lb)

Storage Environment

-40 ℃ to 70 ℃ (-40 ℉ to 158 ℉), Humidity: ≤ 95% RH (non-condensing)

Working Environment

-20 ℃ to 50 ℃ (-4 ℉ to 122 ℉), Humidity: ≤ 95% RH (non-condensing)

Surge Protection

6 KV

Reset Button

Support
