SWITCH UNV NSW5110-24GT4GP-IN

Ethernet

Support frame format: Ethernet II, Support Gigabit SFP,

Support flow control, Support line order (MDIX/MDI),

Support link aggregation,

Support Jumbo Frame Size 9K,

Support port rate adjustment,

Auto, 10M full/half duplex, 100M full/half duplex, 1000M full/half duplex

IEEE802.1d STP

Support IEEE802.1d STP

IEEE802.1w RSTP

Support IEEE802.1w RSTP

MSTP

Support standard 802.1s MSTP,

Support 64 MSTP instances

STP Optional Features

Support port fast,

Support BPDU filter,

Support BPDU guard,

Support hello-time,

Support max age,

Support forward delay,

Support max hops,

Support TC ignore

MSTP Port Optional Features

Support port fast,

Support BPDU filter,

Support BPDU guard,

Support TC guard,

Support TC filter,

Support Auto edge,

Support TC protection,

Support compatibility mode

AP

Support Flow-Balance Methoddst-ip Destination IP address; dst-mac Destination MAC address; src-dst-ip Source and destination IP address; src-dst-mac Source and destination MAC address; src-ip Source IP address; src-mac Source MAC address,

Support AP member port that is included in each AP.

Storm Control

Support multicast storm control, Support control granularity (percentage and kbps are values for 64-byte datagram) 64 kbps, Support broadcast storm control,

Support unicast storm control

Mirroring

Support Many-to-one mirror,

Support Stream-based mirroring,

Support number of mirror groups 4

VLAN

Support whether to allow VLAN 1 to be deleted on the trunk port,

Support port based VLAN,

Support GVRP,

Support the nuber of VLAN that can support be created 4094,

support Mac-VLAN,

Support Subnet-VLAN,

Support Protocol VLAN,

Support VLAN maps

MAC Address

Support gentries MAC address numbers 8K,

Support static MAC address numbers 1024,

Support filtering MAC address numbers 1024,

Support check and delete address table,

Support filtering address

,

Support static address and dynamic learning address

LLDP

Support LLDP

ONVIF

Support ONVIF detect,

Support ONVIF server

IGMP Snooping

Support IGMP snooping groups,

Support IGMP V1, V2 snooping,

Support source IP check,

Support multicast policy and filtering,

Support IGMP fast Leave

Port Limit

Support egress speed limit granularity,

Support Ingress speed limit,

Support egress speed limit

ARP

Support Anti-ARP gateway spoofing,

Support filtering IP port,

Support free ARP protection,

Support source MAC check, Support ARP Detection,

Support IP and Mac static binding,

Support ARP trust port

Network Tool

Support Ping, Support traceroute

ACE Capacities

Support the input direction is associated with the physical port

ACL

Support IP standard ACL,

Support IP extended ACL,

Support professional ACL,

Support Mac extended ACL,

Support global ACL,

Support Time-range ACL

QoS

Support QoS hardware queues,

Support determine the exit queue according to 802.1p, DSCP, port,

Support Stream-based 802.1p Re-marking,

Support Stream-based queue maps,

Support SP,

Support WRR,

Support RR,

Support WFQ

Port Security

Support Mac filtering time,

Support White-list data,

Support clear Mac address table,

Support Mac address binding,

Support max Mac numbers settings,

Support blacklist data,

Support violation mode

Port Isolation

Support

LOOPBACK

Support

DAI

Support software DAI entries

SNMP

Supporting version (SNMPV1, V2c, V3)

Web Management

Support HTTP access

RMON

Support RMON (1, 2, 3, 9)

System Upgrade

Support system upgrade or page upgrade via TFTP

Save Configuration

Support save configuration

Configuration Management

Support Import, export, backup configuration, restore factory configuration

Syslog/Debug

Support Syslog/Debug

Security Function

Support

Basic Characteristics

Support login authentication (password, none)

Password Security

Support static password encryption transmission, storage,

Support strong password and password minimum length check

Radius

Support radius,

Support specify multiple groups of servers IP

Tacacs+

Support specify multiple groups of servers IP

, Support Tacacs+

SSH

Support SSHv2.0

Anti-dos Attack

Support Interrupting land attack packets and illegal TCP packets

Dot1x

Support 802.1X,

Support port base,

Support Mac base,

Support MAB,

Support multiple account switching

Defense Gateway ARP Spoofing

Support defense gateway ARP spoofing

IP Source Guard

Support IP source guard

CPP

Support hardware CPP

ARP Check

Support leverage IP+MAC data binding of IP source guard, Support IP + MAC data binding using DHCP snooping,

Support leverage 1X IP+MAC data binding,

Support trusted ARP

DHCP Relay

Support allow configuration of the number of servers

DHCP Snooping

Support Option82,

Support trust port configuration,

Support IP, MAC binding table(IP Source Guard),

Support bind to logical ports (including physical interfaces),

Support software binding database capacity,

Support bind to VLAN

DHCP Server

Support binding table configuration,

Support address pool configuration

Telnet

Support Telnet,

Support maximum number of connections

TFTP

Support TFTP client

FTP

Support FTP server,

Support FTP client

ERPS

Support delete ERPS loop,

Support ERPS loop configuration,

Support ERPS time configuration

Static And Dynamic LACP Link Aggregation

Support LACP configuration, Support Load-Balance Method; dst-ip Destination IP addressdst-mac Destination MAC address; src-dst-ip Source and destination IP address; src-dst-mac Source and destination MAC address; src-ip Source IP address; src-mac Source MAC address,

Support link aggregation groups,

Support max link aggregation numbers of each link aggregation group,

Support link aggregation port configuration

Ports Type

24×1000Mbps ports (RJ45)+2×1000Mbps Fiber(SFP) ports+2G Combo ports

Standards

IEEE802.3, IEEE802.3u, IEEE802.3z,IEEE802.3ab, IEEE802.3x

Switching capacity

56 Gbps

Forwarding performance

41.66Mpps

Packet Buffer

4 M bit

MAC

8K

Dimensions (W×D×H)

440 × 208 × 44 mm

Weight

<3.6 kg

Power supply

AC: 100-240 V, 50/60 Hz

Storage Temperature

-40 ℃ to 70 ℃

Operating temperature

0 ℃ to 40 ℃ (32 ℉ to 104 ℉)

Operating humidity

10%～90% (non-condensing)

Storage humidity

5%～90% (non-condensing)

Indicator

POWER Steady on: AC input is normal, POWER Off: No AC input, LINK/ACT Steady on: Linked, LINK/AC Green light: connected to 1000 Mbps devices, LINK/ACT Flashing: Transmitting data

Mean Time Between Failure (MTBF)

> 50000 hours
