XVR UNIVIEW XVR301-08F

IP Video Input

2-ch

Analog Video Input

4-ch, BNC

8-ch, BNC

16-ch, BNC

Max IP Video Input

6-ch

10-ch

18-ch

Supported Analog Camera Types

Support AHD input:

1080P@30fps

720P@30fps

Support TVI input:

1080P@30fps

720P@30fps

Support CVI input:

1080P@30fps

720P@30fps

Support CVBS input

HDMI Output

HDMI: 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

VGA Output

VGA: 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

Live View Display

HDMI/VGA: 1/4/6/8/9

HDMI/VGA: 1/4/6/8/9/16

HDMI/VGA: 1/4/6/8/9/25

Recording Resolution

1080P Lite/720P/D1

Recording Frame Rate

Main stream: 1080P Lite@25fps Sub stream: D1@25fps

Main stream: 720P@30fps Sub stream: D1@30fps

Main stream: 1080P Lite@15fps Sub stream: D1@12fps

Main stream: 720P@15fps Sub stream: D1@15fps

Main stream: 1080P Lite@12fps Sub stream: D1@12fps

Main stream: 720P@15fps Sub stream: D1@15fps

Audio Sample Rate

8 kHz, 16 bit per channel

Audio Bit Rate

64 Kbps per channel

Decoding Capability

Analog:4 x 1080P Lite@25, 4 x 720P@30

IP: 1 x 6MP@20, 2 x 1080P@30

Analog:8x 1080P Lite @15, 8x 720P @15

IP: 1 x 6MP@20, 2 x 1080P@30

Analog:16x 1080P Lite@12, 16x 720P@15

IP: 1 x 8MP@30, 2 x 4MP@30, 4 x 1080P@30, 8 x 720P@30,16 x D1@30

Two-way Audio

N/A

FTP/Schedule/Event Snapshot

FTP/Event snapshot:4-ch snapshot, up to 704*576 resolution,

Schedule snapshot:not supported

FTP/Event snapshot:8-ch snapshot, up to 704*576 resolution,

Schedule snapshot:not supported

FTP/Event snapshot:16-ch snapshot, up to 704*576 resolution,

Schedule snapshot:not supported

Incoming Bandwidth

24Mbps (Up to 32Mbps after all analog channel conversion)

24Mbps (Up to 40Mbps after all analog channel conversion)

24Mbps (Up to 56Mbps after all analog channel conversion)

Outgoing Bandwidth

48Mbps

64Mbps

64Mbps

Remote Users

128

Protocols

TCP/IP, P2P, UPnP, NTP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP

Browser(Plugin)

IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+

Analog Smart by XVR

Ultra Motion Detection (UMD)

VCA Search

Behavior Search

Smart Functions by XVR

4-ch (UMD)

8-ch (UMD)

8-ch (UMD)

General Alarm

Motion

Alert Alarm

IP Conflict, Network Disconnected, Disk offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal

GUI Language

20 languages: English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian

SATA

1 SATA interface

Capacity

Up to 6 TB for each HDD

Network Interface

1 RJ45 10 M/100 M self-adaptive Ethernet Interface

USB

Rear panel: 2 × USB2.0

Power Supply

DC 12 V/1.5 A

Working Temperature

-10 ℃ to 55 ℃ (14 ℉ to 131 ℉ )

Working Humidity

≤ 90% RH (non-condensing)

Power Consumption (without HDD)

≤ 10W

Weight (without HDD)

≤0.6 Kg ( 1.32lb )

≤0.6 Kg ( 1.32lb )

≤0.85 Kg ( 1.87lb )

Dimensions

190mm × 202mm × 42mm (7.5" × 7.9" × 1.6")

190mm × 202mm × 42mm (7.5" × 7.9" × 1.6")

253mm × 212mm × 42mm (10.0" × 8.4" × 1.7")

Certification

CE, FCC, UL, RoHS, WEEE

CE

EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035

FCC

Part15 Subpart B
