LAN KABEL UNV CAT6 UTP CAB-LC3100A-E-IN 0.52mm 305M
UNV
259.00 ₼
Cat6 305m UTP Network Cable (OFC 0.5mm Orange)
- Kateqoriya: Kabellər > CAT6 Kabellər
Oxşar məhsullar
|
|
CAB-LC3100A-E-IN |
|||||||
Cable |
||||||||
Product model |
CAB-LC3100A-E-IN |
|||||||
Test Standard |
ISO/IEC11801、TIA-568-C.2 |
|||||||
Product specification |
HSYV-6 4×2×0.52 |
|||||||
Packing length |
305±1m |
|||||||
Ambient temperature |
-20℃～60℃ |
|||||||
Rip-cord |
Yes |
|||||||
Crossing backbone |
Yes |
|||||||
Conductor |
||||||||
AWG |
24 |
|||||||
Nom.O.D.(mm) |
0.52±0.03 mm |
|||||||
DC resistance |
≤95 Ω/km |
|||||||
Material |
OFC(Oxygen free copper) |
|||||||
Insulation |
||||||||
Diameter |
0.93±0.05 mm |
|||||||
Material |
HDPE |
|||||||
Thickness |
0.2±0.02 mm |
|||||||
Color |
Blue/White- Blue,Green/White-Green,Orange/White-Orange,Brown/White-Brown |
|||||||
Pitch |
||||||||
Offset pitch |
≤20 mm |
|||||||
Cable pitch |
≤120 mm |
|||||||
Sheath |
||||||||
Material |
PVC(complies RoHS/REACH) |
|||||||
Thickness |
0.6±0.05 mm |
|||||||
External O.D. |
5.8±0.3 mm |
|||||||
Tensile strength |
>13.5 Mpa |
|||||||
Color |
Orange |
|||||||
Surface Printing |
||||||||
Color |
Black |
|||||||
Letter height |
3.0±0.3 mm |
|||||||
Print error / Space |
1±0.005 m |
|||||||
Case number |
Yes |
|||||||
Packing |
||||||||
Packing |
Carton |
|||||||
Once packing dimension |
420mm*205mm*420mm |
|||||||
Twice packing dimension |
450mm*440mm*445mm |
|||||||
Twice packing quantity |
2 cases |
|||||||
