XVR UNIVIEW XVR302-16Q3

IP Video Input

8-ch

Analog Video Input

16-ch, BNC

Max IP Video Input

24-ch

Supported Analog Camera Types

Support AHD input:

8MP@15fps

5MP@20fps

4MP@30fps

1080P@30fps

720P@30fps

Support TVI input:

8MP@15fps

3K@20fps

5MP@20fps

4MP@30fps

1080P@30fps

720P@30fps

Support CVI input:

8MP@15fps

5MP@25fps

4MP@30fps

1080P@30fps

720P@30fps

Support CVBS input

RCA Audio Input

1-ch

HDMI Output

HDMI: 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

VGA Output

VGA: 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz

BNC Video Output

1-ch

RCA Audio Output

1-ch

Live View Display

HDMI/VGA: 1/4/6/8/9/25

Recording Resolution

8MP Lite/5MP Lite/4MP Lite/1080P/720P/D1

Recording Frame Rate

Main stream: 8MP Lite@8fps Sub stream: D1@8fps

Main stream: 3K Lite@12fps Sub stream: D1@12fps

Main stream: 5MP Lite@12fps Sub stream: D1@12fps

Main stream: 4MP Lite@15fps Sub stream: D1@15fps

Main stream: 1080P@15fps Sub stream: D1@12fps

Main stream: 720P@30fps Sub stream: D1@12fps

Audio Sample Rate

8 kHz, 16 bit per channel

Audio Bit Rate

64 Kbps per channel

Decoding Capability

Analog: 16 x 8MP Lite@8, 16 x 3K Lite@12, 16 x 5MP Lite@12, 16 x 4MP Lite@15, 16 x 1080P@15, 16 x 720@30

IP: 2 x 8MP@30, 4 x 4MP@30, 8 x 1080P@30, 16 x 720P@30, 24 x D1@30

Two-way Audio

1-ch, RCA (Using the audio input and output)

FTP/Schedule/Event Snapshot

Schedule/FTP/Event snapshot:16-ch snapshot, up to 704*576 resolution

Incoming Bandwidth

80Mbps (Up to 112Mbps after all analog channel conversion)

Outgoing Bandwidth

160Mbps

Remote Users

128

Protocols

TCP/IP, P2P, UPnP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP, NTP

Browser(Plugin)

IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+

Analog Smart by XVR

Ultra Motion Detection (UMD) , SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area), Face Detection

IP Smart by IPC

Face Detection, SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area), Defocus Detection, Scene Change Detection, Object Removed, Object Left Behind, Auto Tracking

VCA Search

Face Search, Behavior Search

Smart Functions by XVR

16-ch (UMD), 4-ch (SIP)

Smart Functions by IP Camera

4-ch (SIP)

General Alarm

Motion

Alert Alarm

IP Conflict, Network Disconnected, Disk offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal

GUI Language

38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian

SATA

2 SATA interfaces

Capacity

Up to 16 TB for each HDD (The maximum HDD capacity varies with environment temperature)

Network Interface

1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet Interface

USB

Rear panel: 1 × USB3.0, Front panel: 1 × USB2.0

RS485

1

Alarm In

4-ch

Alarm Out

1-ch

Power Supply

DC 12 V/3 A

Working Temperature

-10 ℃ to 55 ℃ (14 ℉ to 131 ℉ )

Working Humidity

≤ 90% RH (non-condensing)

Power Consumption (without HDD)

≤ 12W

Weight (without HDD)

≤2.0 Kg ( 4.4lb )

Dimensions

380mm ×326mm× 53mm (15.0" × 12.8"×2.1")

Certification

CE, FCC, UL, RoHS, WEEE

CE

EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035

FCC

Part15 Subpart B
